Importance of Circuit Breaker

Modern science has revolutionized the world by introducing electricity and electrical products. However, with electrical products being widely available and used, there come a number of problems. Electrical accidents have become quite frequent and can cause great harm to living beings. Circuit breakers are innovations that keep the flow of electricity smooth and safe. Walton circuit breakers are the most affordable and convenient to use!

What Are Circuit Breakers?

A circuit breaker is an electrical safety device that protects an electrical circuit from overcurrent or short circuit damage. Its primary purpose is to block current flow in order to protect equipment and avoid the risk of fire. Unlike a fuse, which only works once before needing to be replaced, a circuit breaker can be reset (manually or automatically) to return to normal operation.

Circuit breakers come in a variety of sizes, from small devices that safeguard low-current circuits or single household appliances to huge switchgear that protects high-voltage circuits that feed an entire city. A circuit breaker, often known as a fuse, is a device that automatically disconnects electricity from a malfunctioning system.

Components of a Circuit Breaker

A circuit breaker is a device that interrupts aberrant or faults current by switching on and off. It’s a mechanical device that interrupts the flow of high-amplitude (fault) current while also acting as a switch. The circuit breaker’s primary function is to close or open an electrical circuit, thereby protecting the electrical system from damage.

A circuit breaker is made up of both permanent and movable contacts. When the circuit is closed, these contacts are in contact with each other and transporting the current. The current-carrying contacts, known as electrodes, engaged each other under the pressure of a spring when the circuit breaker was closed.

How Does a Circuit Breaker Work?

The arms of the circuit breaker can be opened or closed for system switching and maintenance during normal operating conditions. Only a small amount of pressure on a trigger is necessary to open the circuit breaker.

When a failure occurs in any section of the system, the breaker’s trip coil is triggered, and the movable contacts are separated from one another by some mechanism, allowing the circuit to be opened.

Types of Circuit Breakers:

The medium of arc extinction is the most comprehensive technique for classifying circuit breakers. The following are examples of circuit breakers:-

  • Oil Circuit Breaker
  • Bulk Oil Circuit Breaker
  • Minimum Oil Circuit Breaker
  • Minimum Circuit Breaker
  • Air Blast Circuit Breaker
  • Sulphur Hexafluoride Circuit Breaker
  • Vacuum Circuit Breaker
  • Air Break Circuit Breaker

Features of Walton Circuit Breakers:

– Overload protection

– Short circuit protection

– Isolation

– Controlling

Technical Specifications:

  • Standards: IEC 60898-1
  • Rated current In (A): 6 A
  • Rated voltage Un (VAC): 230/400 V AC
  • Rated frequency (Hz): 50/60 Hz
  • Rated short-circuit capacity (A): 3 KA
  • Rated insulation voltage (VAC): 500 V
  • Number of poles: 1
  • Tripping Curve: C
  • Thermal operating limit (In): 1.13 – 1.45
  • Degree of protection: IP20, with connected conductors
  • Electrical life (times): 10,000
  • Mechanical life (times): 20,000
  • Mounting position: Any,
  • Fire resistance according to UL 94: V0

How Circuit Breakers Prevent Accidents:

In the case of a ground fault, overload, or short circuit in the wiring system, circuit protection devices are designed to automatically limit or shut off the flow of energy. Fuses and circuit breakers protect wires and components from overheating, which could result in fire danger. When the circuit becomes overloaded, they unplug it.

The electrical circuits in your home are protected by a circuit breaker or fuse. When the circuit breaker senses a high current fault, short circuit, or overload, such as when too many appliances are plugged into a single power outlet, it will cut the power.

Importance of Circuit Breakers:

Circuit breakers are more responsive than fuses. Breakers are more dependable than circuit breakers. Circuit breakers are more sensitive than other types of breakers. A circuit breaker can be reset, unlike fuses, which only act once and must be replaced.

Circuit breakers are frequently used to avoid electrical fires and shocks in homes. Circuit breakers have become more common in recent years, as they provide more safety than fuses when used with modern electrical systems.

The objective of circuit breakers today is to assist keep houses safe from previously invisible electrical risks. When a circuit breaker senses a problem on the circuit that could result in an electrical fire or shock, it turns off the electricity. Here’s a look at the two types of circuit breakers to help you better understand how they protect your property.

How to Prevent Electrical Accidents:

It is critical to remember that when working with electricity, there is always the potential for electric shock incidents, which can be fatal in some cases. As a result, you should always keep the following security precautions in mind.

At least once a month, check the operation of your house or company CB. Circuit breakers, regardless of brand or origin, have a test button for this purpose. The lever is damaged if pressing the button does not activate it.

Never use bare feet to operate an electrical device or wet hands or feet to operate a switch.

To avoid future mishaps, it is suggested that a competent electrician perform revision and maintenance work on older installations. On windy and stormy days, avoid working on the roof near electrical power cables to avoid mishaps.

To avoid electrical surges, utilize one outlet for each use as much as feasible, rather than T-Taps or similar devices.

Why You Should Buy Walton Circuit Breakers:

Walton produces high-quality circuit breakers at a reasonable price. There are a lot of options to pick from. You never have to worry about the quality of their products because they are 100 percent genuine. Contact your local retailer or go to their website to discover more about Walton’s creative and energy-efficient circuit breakers. Get the best electronic gadgets from the most recognized company in Bangladesh!
